| Connectors | |
| Serial | 1 x DB-9 Male (Black) |
| Network | 1 x RJ-45 Female (Black) |
| Power | 1 x 2-pin Terminal Block (Green) 1 x DC Jack (Black) |
| Switches | |
| Reset | 1 x Semi-recessed Pushbutton |
| LEDs | |
| Power | 1 (Green) |
| Link | 1 (Green) |
| 10/100 Mbps | 1 (Orange/Green) |
| TxRx (ACT) | 1 (Green) |
| Power Inputs | |
| Power Adapter | 100-240V AC; 50/60 Hz |
| Power Line Protection | 4KV burst (EFT), EN61000-4-4 2KV surge, EN61000-4-4 |
| Power Consumption | DC9V:2.28W:11BTU |
| Interfaces | |
| Serial | RS-232/422/485; Software selectable RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND RS-422: Tx+, Tx-, Rx+, Rx-, RTS+, RTS-, CTS+, CTS-, GND RS-485: Data+, Data-, GND Baud Rate: 460Kbps Protection: 15 KV ESD Protection for the serial port Parity: None, Even, Odd, Mark, Space Data Bits: 5, 6, 7, 8 Stop Bits: 1, 1.5, 2 Flow Control: None, XON/XOFF, RTS/CTS |
| Network | 10/100BaseTX; Autosensing ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IP, TCP, UDP, NTP, PPP, RADIUS, Telnet, SNMP, SNMP Trap, SMTP, SSH Protection: 1.5 KV Magnetic Isolation |
| Compliance | FCC Class A, CE Class A, RoHS |
| Environmental | |
| Operating Temperature | 0 – 60°C |
| Storage Temperature | -20 – 85°C |
| Humidity | 0 ~ 95% RH, Non-condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 0.22 kg ( 0.48 lb ) |
| Dimensions (L x W x H) | 10.69 x 7.90 x 2.44 cm (4.21 x 3.11 x 0.96 in.) |
| Note | For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
